231-739/001-000

THT male header, 1.0 x 1.0 mm solder pin, straight, Pin spacing 7.62 mm, 9-pole, orange

Manufacturer's No: 231-739/001-000     Manufacturer: WAGO
THT male header, 1.0 x 1.0 mm solder pin, straight, Pin spacing 7.62 mm, 9-pole, orange

Availability Back Order

POA
  • THT male header
  • 1.0 x 1.0 mm solder pin, straight
  • Pin spacing: 7.62 mm
  • 9-pole
  • Color: Orange

Accessories

Coding key, snap-on type, light gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 231-130
Price £0.08
Back Order

Spacer, for formation of groups, light gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 231-500
Price £0.03
Back Order


Product

Manufacturer Material ID -
231-739/001-000
Net Weight -
0.24kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
Minimum Order Quantity -
50
UNSPSC -
39121402

Technical Specification

Diameter connection pin -
- Millimetre
Colour housing -
Orange
Operation temperature -
-60 Degrees celsius
Angle PCB/contact -
90° (upwards vertical)
Connector model -
Free connector
Contact type -
Pin
Housing colour -
Orange
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
5 Millimetre
Material insulation body -
Thermoplastic
Material of contact surface -
Tin
Modular spacing connections -
7.62 Millimetre
Modular spacing contacts -
7.62 Millimetre
Number of plug-in contact rows -
1
Number of poles -
9
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
12 Ampere
Rated surge voltage -
6 Kilovolt
Rated voltage -
630 Volt
Suitable for PCB thickness -
1.5 Millimetre
Type of banding -
None
Type of connection -
Flexible PCB-connector
Type of electric connection -
Soldering connection
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Back Order

POA
