3RK13045LS402AA0

ET 200pro DSE HF DOL starter High Feature Mechanical switching Electronic overload protection AC-3,

Manufacturer's No: 3RK1304-5LS40-2AA0     Manufacturer: Siemens
ET 200pro DSE HF DOL starter High Feature Mechanical switching Electronic overload protection AC-3,

View 3D

Availability Back Order

£503.71
  • ET 200pro DSE HF DOL starter
  • High Feature Mechanical switching
  • Electronic overload protection
  • AC-3, 5.5 kW / 400 V
  • Current range: 1.50 A to 12.00 A
  • Without brake contact
  • 4 Digital Inputs: Han Q4/2 - Han Q8/0

Accessories

Labeling plates 20x7 mm titanium-gray

Product Code - 3RT29001SB20
Price £0.22
Back Order

AS-i accessory M12 cover for IP67 modules

Product Code - 3RK19011KA00
Price £1.09
In Stock

Sealing cap for 9-pole power sockets

Product Code - 3RK19020CJ00
Price £7.35
Back Order


Product

Manufacturer Material ID -
3RK1304-5LS40-2AA0
Net Weight -
1.70kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Number of command positions -
-
Number of auxiliary contacts as normally open contact -
-
Number of auxiliary contacts as normally closed contact -
-
Number of indicator lights -
-
Rated control supply voltage Us at AC 50HZ -
- Volt
Rated control supply voltage Us at AC 60HZ -
- Volt
Type of electrical connection for auxiliary- and control current circuit -
UN
Rated operation power at AC-3, 230 V, 3-phase -
- Kilowatt
Rated power, 460 V, 60 Hz, 3-phase -
- Kilowatt
Rated power, 575 V, 60 Hz, 3-phase -
- Kilowatt
Ambient temperature, upper operating limit -
- Degrees celsius
Rated conditional short-circuit current, type 2, 400 V -
- Ampere
Rated conditional short-circuit current, type 2, 230 V -
- Ampere
Rated conditional short-circuit current, type 1, 480 Y/277 V -
- Ampere
Rated conditional short-circuit current, type 1, 600 Y/347 V -
- Ampere
Degree of protection (NEMA) -
UN
Rated control supply voltage Us at DC -
20.4 Volt
Degree of protection (IP) -
IP65
Coordination class according to IEC 60947-4-3 -
Class 1
Degree of protection (IP rating) -
IP65
Depth -
150 Millimetre
Height -
230 Millimetre
Kind of motor starter -
Direct starter
Overload release current setting -
1.5 Ampere
Rated control supply voltage at DC -
20.4 Volt
Rated operation current at AC-3, 400 V -
12 Ampere
Rated operation current Ie -
12 Ampere
Rated operation power at AC-3, 400 V -
5.5 Kilowatt
Release class -
CLASS 10
Type of electrical connection of main circuit -
Flat plug-in connection
Voltage type for actuating -
DC
Width -
110 Millimetre
With short-circuit release -

Availability Back Order

£503.71
