3NP11331CA12

SENTRON, Fuse switch disconnector 3NP1, 3-pole, NH00, 160 A, for assembly and installation on mounti

Manufacturer's No: 3NP1133-1CA12     Manufacturer: Siemens
SENTRON, Fuse switch disconnector 3NP1, 3-pole, NH00, 160 A, for assembly and installation on mounti

Availability Back Order

£190.06
  • Product: SENTRON Fuse Switch Disconnector 3NP1
  • Configuration: 3-pole, NH00
  • Current Rating: 160 A
  • Mounting: Designed for assembly on a mounting plate
  • Terminal Type: Flat terminal
  • Fuse Monitoring: Electronic EFM10
  • Cover Level: 45 mm

Selectable mandatory product

Accessories

Component part

Product video
Product video


Product

Manufacturer Material ID -
3NP1133-1CA12
Net Weight -
1.07kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
EAR99 / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Rated operation power at AC-23, 400 V -
- Kilowatt
Rated short-time withstand current lcw -
- kiloampere
Suitable for ground mounting -
Cable entry -
Other
Conditioned rated short-circuit current Iq -
80 kiloampere
Degree of protection (IP), front side -
IP40
Max. rated operation voltage Ue AC -
690 Volt
Number of poles -
3
Position control element -
Front
Rated permanent current Iu -
160 Ampere
Suitable for floor mounting -
Suitable for fuses -
NH000, NH00
Type of control element -
Cover grip
Type of electrical connection of main circuit -
Rail connection
Version as safety switch -
With error protection -

Availability Back Order

£190.06
