540203

SDE3-D2D-B-HQ4-2P-M8 Pressure sensor

Manufacturer's No: SDE3-D2D-B-HQ4-2P-M8     Manufacturer: Festo
SDE3-D2D-B-HQ4-2P-M8 Pressure sensor

Availability Available to order

£185.40
  • Pressure sensor model: SDE3-D2D-B-HQ4-2P-M8
  • Measured variable: 2 x relative pressure
  • Measurement method: Piezoresistive pressure sensor with display
  • Pressure measuring range: 0 to 0.2 MPa, 0 to 2 bar, 0 to 29 psi
  • Operating medium: Compressed air (ISO 8573-1:2010 [7:4:4]), lubricated operation possible
  • Media temperature range: 0°C to 50°C
  • Ambient temperature range: 0°C to 50°C
  • Accuracy: ±2% FS
  • Switching output: 2x PNP, freely programmable
  • Reproducibility of switching value: 0.3%

Read more

  • Max. output current: 100 mA, pulsed short circuit current rating
  • Operational voltage range DC: 15V to 30V, reverse polarity protection
  • Electrical connection: M8x1 A-coded plugs, 4 connections/cores, screw-type lock
  • Mounting: With through-hole, H-rail, optional position
  • Pneumatic connection: QS-4
  • Product weight: 37 g
  • Material housing: PA-reinforced PC
  • Display: Illuminated LCD, switching status indication in yellow
  • Setting options: Teach-in, PIN code for tamper protection
  • Setting range threshold value: 0% to 100%, hysteresis: 0% to 90%
  • Degree of protection: IP65, corrosion resistance class CRC: 2
  • LABS (PWIS) conformity: VDMA24364-B1/B2-L
  • Cleanroom class: Class 4 according to ISO 14644-1

Accessories



Product

Manufacturer Material ID -
SDE3-D2D-B-HQ4-2P-M8
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
CH
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Suitable for safety functions -
Type of interface for safety communication -
None
Type of electric connection -
Connector M12
Interface type -
None
Ambient temperature during operating -
-25 Degrees celsius
Height of sensor -
75 Millimetre
Length of sensor -
40 Millimetre
Width sensor -
40 Millimetre
