KVI-CP-3-GS-GD-2 Connecting cable

Manufacturer's No: KVI-CP-3-GS-GD-2     Manufacturer: Festo
KVI-CP-3-GS-GD-2 Connecting cable

Availability On Request

£63.39
  • Connecting cable KVI-CP-3-GS-GD-2
  • Socket M9, straight, 5-pin/-wire
  • Cable TPE-U(PUR), standard, 2m length, 0.25 mm², 0.34 mm², 0.49 mm²
  • Plug M9, straight, 5-pin/-wire, IP65/IP67
  • Additional function: Contact 3 of socket 1mm leading
  • Frequency of connection: 500
  • Product weight: 113.8g
  • Electrical connection 1: Field device side, round design, socket connection, M9x0.5 connector system, 5 connections/cores, screw-type lock
  • Electrical connection 2: Controller side, round design, plug connection, M9x0.5 connector system, 5 connections/cores, screw-type lock
  • Operational voltage range DC: 0V to 30V

Read more

  • Current rating at 40°C: 1.6A, 2.3A for 0.34 mm², 3.6A for 0.49 mm²
  • Immunity to surge: 1.5KV
  • Shielding: Yes
  • Cable length: 2m, suitable for energy chains
  • Bending radius, moving cable: 75mm
  • Cable diameter: 5.5mm
  • Cable structure: 2 x 0.25 mm² + 2 x 0.34 mm² + 0.49 mm²
  • Degree of protection: IP65, IP67
  • Ambient temperature: -20°C to 80°C, -5°C to 80°C with moving cable
  • CE mark: In accordance with EU RoHS Directive
  • UKCA marking: To UK RoHS instructions
  • LABS (PWIS) conformity: VDMA24364-B2-L
  • Pollution degree: 1
  • Corrosion resistance class CRC: 1 - Low corrosion stress
  • Material: Cable sheath - TPE-U(PUR), light grey color; Housing - PA, PBT, TPE-U(PUR), black color; Screw-type lock - Nickel-plated brass; Electrical contact - Gold-plated bronze, gold-plated brass; Insulating sheath - TPE-U(PUR)


Product

Manufacturer Material ID -
KVI-CP-3-GS-GD-2
Net Weight -
0.12kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
UNSPSC -
26121629

Technical Specification

Accessory -
Type of accessory/spare part -
Other
