5TT58311

INSTA contactor with 3 NO contacts and 1 NC, contact for 230 V, 400 V AC 25 A activation 115 V

Manufacturer's No: 5TT5831-1     Manufacturer: Siemens
INSTA contactor with 3 NO contacts and 1 NC, contact for 230 V, 400 V AC 25 A activation 115 V AC

Availability Back Order

£58.57
  • Contactor type: INSTA
  • Contacts: 3 NO, 1 NC
  • Voltage: 230 V AC control, 400 V, 25A
  • Control voltage: 115 V AC

Accessories

Spacer 0.5 MW

Product Code - 5TG8240
Price £4.76
Back Order

Sealing cap for 5TT583.

Product Code - 5TT59106
Price £1.76
Back Order


Product

Manufacturer Material ID -
5TT5831-1
Net Weight -
0.26kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
SI
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Utility category -
-
Max. load fluorescent lamp -
- Voltampere
Max. load fluorescent lamp (Duo circuit) -
- Voltampere
Max. load fluorescent lamp (parallel compensated) -
- Voltampere
Built-in depth -
0 Millimetre
Number of modular spacings -
2
Degree of protection (IP) -
IP20
Additional equipment possible -
Degree of protection (IP rating) -
IP20
Max. incandescent lamp load -
2000 Watt
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
3
Rated excitation voltage -
115 Volt
Rated operating voltage -
440 Volt
Rated operation current -
25 Ampere
Recess depth -
0 Millimetre
Voltage type (excitation voltage) -
AC
Voltage type (operating voltage) -
AC
Width in number of modular spacings -
2

Availability Back Order

£58.57
