5SJ41608HG40

Miniature circuit breaker 240 V 10kA, 1-pole, D, 60A, D=70 mm according to UL 489, equal polarity

Manufacturer's No: 5SJ4160-8HG40     Manufacturer: Siemens
Miniature circuit breaker 240 V 10kA, 1-pole, D, 60A, D=70 mm according to UL 489, equal polarity

View 3D

Availability Back Order

£105.30
  • Miniature circuit breaker
  • Voltage: 240 V
  • Breaking capacity: 10 kA
  • Configuration: 1-pole
  • Current rating: 60A
  • Dimensions: 70 mm (Diameter)
  • Compliant with UL 489
  • Equal polarity

Selectable mandatory product

Accessories

Product video
Product video


Product

Manufacturer Material ID -
5SJ4160-8HG40
Net Weight -
0.17kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Current limiting class -
-
Connectable conductor cross section solid-core -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Rated impulse withstand voltage Uimp -
- Kilovolt
Built-in depth -
70 Millimetre
Release characteristic -
D
Degree of protection (IP) -
IP20
Frequency -
50 Hertz
Degree of protection (IP rating) -
IP20
Number of protected poles -
1
Additional equipment possible -
Ambient temperature during operating -
-25 Degrees celsius
Number of poles (total) -
1
Over voltage category -
3
Pollution degree -
3
Rated current -
60 Ampere
Rated insulation voltage Ui -
440 Volt
Rated short-circuit breaking capacity Icn EN 60898 at 230 V -
10 kiloampere
Rated short-circuit breaking capacity Icn EN 60898 at 400 V -
10 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V -
15 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V -
15 kiloampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Tripping characteristic (type/curve) -
D
Voltage type -
AC/DC
Width in number of modular spacings -
1

Availability Back Order

£105.30
