5SJ63167KS

Miniature circuit breaker 400 V 6kA, 3-pole, C, 16A, D=70 mm with screwless outgoing terminals

Manufacturer's No: 5SJ6316-7KS     Manufacturer: Siemens
Miniature circuit breaker 400 V 6kA, 3-pole, C, 16A, D=70 mm with screwless outgoing terminals

Availability On Request

£54.36
  • Miniature circuit breaker
  • Voltage: 400 V
  • Breaking capacity: 6 kA
  • Poles: 3
  • Type: C
  • Current rating: 16A
  • Dimensions: 70 mm
  • Screwless outgoing terminals

Selectable mandatory product

PIN BUSBAR.16SQMM,3PH,FI NLI+8XPH

Product Code - 5ST3668
Price £14.62
On Request
Question and Answer (Q&A video)
Product video
Question and Answer (Q&A video)
Product video


Product

Manufacturer Material ID -
5SJ6316-7KS
Net Weight -
0.35kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
RO
Export Control Regulations -
N / N
UNSPSC -
39121601

Technical Specification

Rated impulse withstand voltage Uimp -
- Kilovolt
Built-in depth -
70 Millimetre
Release characteristic -
C
Degree of protection (IP) -
IP20
Frequency -
50 Hertz
Degree of protection (IP rating) -
IP20
Number of protected poles -
3
Ambient temperature during operating -
-25 Degrees celsius
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Connectable conductor cross section solid-core -
0.75 Square millimetre
Current limiting class -
3
Number of poles (total) -
3
Over voltage category -
3
Pollution degree -
2
Rated current -
16 Ampere
Rated insulation voltage Ui -
440 Volt
Rated short-circuit breaking capacity Icn EN 60898 at 230 V -
6 kiloampere
Rated short-circuit breaking capacity Icn EN 60898 at 400 V -
6 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V -
6 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V -
6 kiloampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Tripping characteristic (type/curve) -
C
Voltage type -
AC/DC
Width in number of modular spacings -
3

Availability On Request

£54.36
