5SM37474

Residual current operated circuit breaker, 4-pole, type B, short-time delayed, In: 80 A, 500 mA, Un

Manufacturer's No: 5SM3747-4     Manufacturer: Siemens
Residual current operated circuit breaker, 4-pole, type B, short-time delayed, In: 80 A, 500 mA, Un

Availability On Request

POA

This product has been superseded by

5SV37474

Please check compatibility before purchasing.

  • Residual current operated circuit breaker
  • 4-pole, type B
  • Short-time delayed
  • Rated current: 80 A
  • Sensitivity: 500 mA
  • Discontinued since: 30/09/22
  • Successor model: 5SV3747-4

Accessories

Price £0.0836
On Request
Price £0.0836
On Request

Follow-up article



Product

Manufacturer Material ID -
5SM3747-4
Net Weight -
0.55kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
DE
Export Control Regulations -
EAR99 / N
UNSPSC -
39121626

Technical Specification

Additional equipment possible -
Ambient temperature during operating -
-25 Degrees celsius
Connectable conductor cross section multi-wired -
1.5 Square millimetre
Connectable conductor cross section solid-core -
1.5 Square millimetre
Frequency -
50 Hz
Leakage current type -
B
Number of poles -
4
Rated current -
80 Ampere
Rated fault current -
0.5 Ampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Short-circuit breaking capacity (Icw) -
10 kiloampere
Short-time delayed tripping -
Surge current capacity -
3 kiloampere
Voltage type -
AC
Width in number of modular spacings -
4
With interlocking device -

Availability On Request

POA
Sign in or Register for customer prices.

This product has been superseded by

5SV37474

Please check compatibility before purchasing.
