6AV66470AH113AX0

KP300 Basic PN - 3.6" Mono + 10 keys

Manufacturer's No: 6AV6647-0AH11-3AX0     Manufacturer: Siemens
KP300 Basic PN - 3.6" Mono + 10 keys

View 3D

Availability Back Order

POA

This product has been superseded by

6AV66470AH113AX1

Please check compatibility before purchasing.

  • Model: KP300 Basic PN
  • Display: 3.6" Monochrome
  • Keypad: 10 keys
  • Product cancelled since: 08/08/22
  • Successor model: 6AV6647-0AH11-3AX1
  • Sparepart product
  • For assistance, contact local Siemens office

Accessories



Product

Manufacturer Material ID -
6AV6647-0AH11-3AX0
Net Weight -
0.38kg

Additional Product Information

Commodity Code -
85371099
Country of Origin -
CN
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
43201503

Technical Specification

-
Siemens
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Degree of protection (NEMA), front side -
UN
Built-in depth -
30 Millimetre
Operation temperature -
0 Degrees celsius
Number of interfaces PROFINET -
1
Type of display -
STN
Degree of protection (IP), front side -
IP65
Height of the front -
97 Millimetre
Number of buttons with LED -
0
Number of colours of the display -
4
Number of function buttons, programmable -
10
Number of grey-scales/blue-scales of display -
0
Number of HW-interfaces industrial Ethernet -
1
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
1
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Number of online languages -
5
Number of password levels -
50
Number of pixels, horizontal -
240
Number of pixels, vertical -
80
Number of system buttons -
10
Operating temperature -
0 Degrees celsius
Process default value (input) possible -
Process value representation (output) possible -
Recess depth -
30 Millimetre
Screen diagonal -
3.6 inch
Supply voltage DC -
19.2 Volt
Supporting protocol for EtherNet/IP -
Supporting protocol for MODBUS -
Supporting protocol for TCP/IP -
Touch technology -
None
Useful project memory/user memory -
1000 kiloByte (1000 Byte)
Voltage type of supply voltage -
DC
Width of the front -
165 Millimetre
With alpha numeric keyboard -
With colour display -
With message indication -
With message system (incl. buffer and confirmation) -
With numeric keyboard -
With recipes -

Availability Back Order

POA
Sign in or Register for customer prices.

This product has been superseded by

6AV66470AH113AX1

Please check compatibility before purchasing.
