6ES71314FB000AB0

ET200S 2DI, 2 Inputs, 230Vac, Standard (Pack Of 5) , (terminal type A or B required)

Manufacturer's No: 6ES7131-4FB00-0AB0     Manufacturer: Siemens
ET200S 2DI, 2 Inputs, 230Vac, Standard (Pack Of 5) , (terminal type A or B required)

Availability On Request

POA
  • Product: ET200S 2DI
  • Inputs: 2
  • Voltage: 230V AC
  • Width: 15mm
  • Packaging: Pack of 5
  • Terminal type: A or B required
  • Suitable for SIMATIC DP
  • Includes 5 electronic modules
  • Each module has 2 DI inputs at 230V AC
  • 5 units per pack

Accessories



Product

Manufacturer Material ID -
6ES7131-4FB00-0AB0
Net Weight -
0.17kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

-
Siemens
Output current -
- Ampere
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage DC -
- Volt
Permitted voltage at output -
- Volt
Type of output voltage -
UN
SIL according to IEC 61508 -
UN
Time delay at signal exchange -
15 Millisecond
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
0
Front build in possible -
Type of electric connection -
Screw-/spring clamp connection
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust -
None
Degree of protection (IP rating) -
IP20
Depth -
52 Millimetre
Digital inputs configurable -
Fieldbus connection over separate bus coupler possible -
Height -
81 Millimetre
Input current at signal 1 -
5 Milliampere
Number of digital inputs -
2
Number of digital outputs -
0
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Permitted voltage at input -
0 Volt
Rail mounting possible -
Supply voltage AC 50 Hz -
192 Volt
Supply voltage AC 60 Hz -
192 Volt
System accessory -
Time delay at signal change -
15 Millisecond
Type of digital output -
None
Type of voltage (input voltage) -
AC
Voltage type of supply voltage -
AC
Width -
15 Millimetre

Availability On Request

POA
