6ES71384DB030AB0

ET200S SSI, 1 channel SSI encoder reading module, (terminal type A or B required)

Manufacturer's No: 6ES7138-4DB03-0AB0     Manufacturer: Siemens
ET200S SSI, 1 channel SSI encoder reading module, (terminal type A or B required)

View 3D

Availability Back Order

POA
  • ET200S SSI module for reading 1 channel SSI encoder
  • Compatible with terminal type A or B
  • Electronics module for ET 200S with 1 SSI 25-bit/1 MHz
  • Designed for connecting absolute value encoders with SSI interface
  • Includes DI, comparison value, and clock synchronization
  • Compact design with 15mm width

Accessories



Product

Manufacturer Material ID -
6ES7138-4DB03-0AB0
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

-
Siemens
Number of functions -
-
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
0
Front build in possible -
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Degree of protection (IP rating) -
IP20
Depth -
52 Millimetre
Explosion safety category for dust -
None
Function electronic positioning available -
Height -
81 Millimetre
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Rail mounting possible -
Single-axis positioning possible -
Suitable for detection absolute value -
Suitable for incremental data detection -
Suitable for SSI -
Supply voltage DC -
20.4 Volt
System accessory -
Voltage type of supply voltage -
DC
Width -
15 Millimetre

Availability Back Order

POA
