6SL32240XE416UA0

PM240 without filter - 160kW (302 A) (CT), 200kW (370 A) (VT), (FSGX)

Manufacturer's No: 6SL3224-0XE41-6UA0     Manufacturer: Siemens
PM240 without filter - 160kW (302 A) (CT), 200kW (370 A) (VT), (FSGX)

Availability Back Order

POA

This product has been superseded by

6SL32101PE337CL0

Please check compatibility before purchasing.

  • Power Output: 160 kW (302 A) in CT, 200 kW (370 A) in VT
  • Input: 3AC 380-480V +/-10% 47-63Hz
  • High Overload Capacity: 160 kW for 160% 3s, 136% 57s, 100% 240s at 0 to +50°C
  • Light Overload Capacity: 200 kW for 150% 3s, 110% 57s, 100% 240s at 0 to +40°C
  • Dimensions: 1533 x 326 x 545 mm (H x W x D)
  • Protection: IP20
  • Features: No built-in braking chopper, no control unit and BOP
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
6SL3224-0XE41-6UA0
Net Weight -
183.00kg

Additional Product Information

Commodity Code -
85044088
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32121705

Technical Specification

-
Siemens
Number of digital inputs -
-
Number of digital outputs -
-
Number of analogue inputs -
-
Number of analogue outputs -
-
Number of HW-interfaces industrial Ethernet -
-
Number of HW-interfaces RS-232 -
-
Number of HW-interfaces RS-422 -
-
Number of HW-interfaces RS-485 -
-
Number of HW-interfaces serial TTY -
-
Number of HW-interfaces USB -
-
Number of HW-interfaces parallel -
-
Number of HW-interfaces other -
-
Number of interfaces PROFINET -
-
Max. output voltage -
- Volt
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Mains frequency -
50/60 Hz
Depth -
547 Millimetre
Height -
1533 Millimetre
Mains voltage -
380 Volt
Max. output at linear load at rated output voltage -
160 Kilowatt
Max. output at quadratic load at rated output voltage -
200 Kilowatt
Max. output frequency -
550 Hertz
Nominal output current I2N -
370 Ampere
Number of phases input -
3
Number of phases output -
3
Relative symmetric net frequency tolerance -
5 Percentage
Relative symmetric net voltage tolerance -
-10 Percentage
Type of converter -
U converter
Width -
326 Millimetre

Availability Back Order

POA
Sign in or Register for customer prices.

This product has been superseded by

6SL32101PE337CL0

Please check compatibility before purchasing.
