6AG25221BH014AB0

SIPLUS S7-1500 DQ 16x24 V DC HF TX RAIL -40 ... +70 °C TX with 85°C for 10 min with conformal coat

Manufacturer's No: 6AG2522-1BH01-4AB0     Manufacturer: Siemens
SIPLUS S7-1500 DQ 16x24 V DC HF TX RAIL -40 ... +70 °C TX with 85°C for 10 min with conformal coat

Availability On Request

£471.00
  • Model: SIPLUS S7-1500 DQ 16x24VDC HF TX
  • Part Number: 6ES7522-1BH01-0AB0
  • Conformal coating for protection
  • Operating temperature: -40°C to +70°C, with temporary exposure up to +85°C for 10 minutes
  • Digital output module with 16 channels in groups of 8
  • Output current: 4A per group
  • Single-channel diagnostics for troubleshooting
  • Substitute value feature included

Mandatory additional product

Selectable mandatory product

Accessories

Spare part



Product

Manufacturer Material ID -
6AG2522-1BH01-4AB0
Net Weight -
0.28kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
EAR99H / N
Minimum Order Quantity -
1
UNSPSC -
32151705

Technical Specification

Input current at signal 1 -
- Milliampere
Type of voltage (input voltage) -
UN
Type of electric connection -
UN
Explosion safety category for gas -
UN
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Permitted voltage at input -
- Volt
SIL according to IEC 61508 -
UN
Time delay at signal exchange -
0.1 Millisecond
Explosion safety category for dust -
None
Depth -
129 Millimetre
Digital outputs configurable -
Height -
147 Millimetre
Number of digital inputs -
0
Number of digital outputs -
16
Output current -
0.5 Ampere
Permitted voltage at output -
0 Volt
Redundancy -
Short-circuit protection, outputs available -
Supply voltage DC -
20.4 Volt
Time delay at signal change -
0.1 Millisecond
Type of digital output -
Transistor
Type of output voltage -
DC
Voltage type of supply voltage -
DC
Width -
35 Millimetre

Availability On Request

£471.00
