6SL32105BB180AV0

SINAMICS V20 200-240 V 1-phase-AC -10/+10 Rated power 0.75/1 PS with 150% overload for 60 sec. Integ

Manufacturer's No: 6SL3210-5BB18-0AV0     Manufacturer: Siemens
SINAMICS V20 200-240 V 1-phase-AC -10/+10 Rated power 0.75/1 PS with 150% overload for 60 sec. Integ

Availability Available to order

POA

This product has been superseded by

6SL32105BB175BV1

Please check compatibility before purchasing.

  • SINAMICS V20
    • Input Voltage: 200-240 V
    • Phase: 1-phase AC
    • Rated Power: 0.75/1 PS
    • Overload Capacity: 150% for 60 sec
    • Discontinued since: 01/10/17
    • Successor: 6SL3210-5BB17-5BV1

Follow-up article

Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
6SL3210-5BB18-0AV0
Net Weight -
1.40kg

Additional Product Information

Commodity Code -
85044087
Country of Origin -
CN
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
UNSPSC -
32121705

Technical Specification

Application in industrial area permitted -
Depth -
145.5 Millimetre
Height -
166 Millimetre
Mains voltage -
200 Volt
Max. output at linear load at rated output voltage -
0.75 Kilowatt
Max. output at quadratic load at rated output voltage -
0.75 Kilowatt
Max. output frequency -
550 Hertz
Max. output voltage -
240 Volt
Nominal output current I2N -
4.2 Ampere
Number of analogue inputs -
2
Number of analogue outputs -
1
Number of digital inputs -
4
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
1
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
1
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
1
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of phases input -
1
Number of phases output -
3
Relative symmetric net frequency tolerance -
5 Percentage
Relative symmetric net voltage tolerance -
-10 Percentage
Supporting protocol for MODBUS -
Supporting protocol for other bus systems -
Type of converter -
U converter
Width -
90 Millimetre
Commodity Code -
85044087

Availability Available to order

POA
Sign in or Register for customer prices.

This product has been superseded by

6SL32105BB175BV1

Please check compatibility before purchasing.
