6SL33101PE346AA0

SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10

Manufacturer's No: 6SL3310-1PE34-6AA0     Manufacturer: Siemens
SINAMICS G120P POWER MODULE PM330 WITHOUT FILTER WITHOUT BULT IN BRAKING CHOPPER 3AC380-480V +10/-10

Availability Back Order

£17,687.28
  • Power Module: SINAMICS G120P PM330
  • Input Voltage: 3AC 380-480V +/-10% 47-63Hz
  • Output Overload: 200kW for 150% for 60s, 100% for 240s
  • Light Overload: 250kW for 110% for 60s, 100% for 240s
  • Ambient Temperature: 0 to +40°C
  • Dimensions: 1447 x 452 x 328 mm (HxWxD)
  • Protection: IP20
  • Features: Without filter, built-in braking chopper, without control unit and panel
  • Compatibility: Approved with CU230P-2 firmware version V4.6

Selectable mandatory product

Accessories

Instructional video
Instructional video


Product

Manufacturer Material ID -
6SL3310-1PE34-6AA0
Net Weight -
122.00kg

Additional Product Information

Commodity Code -
85044088
Country of Origin -
DE
Export Control Regulations -
EAR99H / N
Minimum Order Quantity -
1
UNSPSC -
32121705

Technical Specification

Number of digital inputs -
-
Number of digital outputs -
-
Number of analogue inputs -
-
Number of analogue outputs -
-
Number of HW-interfaces industrial Ethernet -
-
Number of HW-interfaces RS-232 -
-
Number of HW-interfaces RS-422 -
-
Number of HW-interfaces RS-485 -
-
Number of HW-interfaces serial TTY -
-
Number of HW-interfaces USB -
-
Number of HW-interfaces parallel -
-
Number of HW-interfaces other -
-
Number of interfaces PROFINET -
-
Max. output voltage -
- Volt
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Degree of protection (IP rating) -
IP20
Mains frequency -
50/60 Hz
Application in industrial area permitted -
Depth -
327 Millimetre
Height -
1447 Millimetre
Mains voltage -
380 Volt
Max. output at linear load at rated output voltage -
200 Kilowatt
Max. output at quadratic load at rated output voltage -
250 Kilowatt
Max. output frequency -
100 Hertz
Nominal output current I2N -
460 Ampere
Number of phases input -
3
Number of phases output -
3
Relative symmetric net frequency tolerance -
5 Percentage
Relative symmetric net voltage tolerance -
10 Percentage
Type of converter -
U converter
Width -
452 Millimetre

Availability Back Order

£17,687.28
