8WH12010BK01

N conductor isolating terminal for installation terminal, conductor cross-section 16 mm2 color blue

Manufacturer's No: 8WH1201-0BK01     Manufacturer: Siemens
N conductor isolating terminal for installation terminal, conductor cross-section 16 mm2 color blue

Availability Back Order

£10.34
  • Terminal type: Screw terminal
  • Installation type: N conductor isolating terminal
  • Conductor size: 16 mm²
  • Color: Blue

Accessories

N BAR 10X3MM

Product Code - 8WH90302AB12
Price £30.80
Back Order


Product

Manufacturer Material ID -
8WH1201-0BK01
Net Weight -
0.03kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121410

Technical Specification

Colour -
Blue
Connectable conductor cross section fine-strand with cable end sleeve -
6 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
6 Square millimetre
Connectable conductor cross section multi-wired -
2.5 Square millimetre
Connectable conductor cross section solid-core -
6 Square millimetre
Connecting plate required -
Depth -
12.2 Millimetre
Height -
49.9 Millimetre
Inflammability class of insulation material acc. with UL94 -
V2
Mounting method -
DIN rail (top hat rail) 35 mm
Number of clamp positions -
2
Operating temperature -
-60 Degrees celsius
Rated current In -
76 Ampere
Rated voltage -
400 Volt
Suitable for N-busbar -
3x10 mm
Type of electric connection -
Screw connection
Width -
56 Millimetre

Availability Back Order

£10.34
