2310800 {T}

Capacitive Sensor, Operating voltage 20…250 VAC, Rated switching distance

Manufacturer's No: BC10-S30-RZ3X     Manufacturer: Turck Banner
Capacitive Sensor, Operating voltage 20…250 VAC, Rated switching distance

Availability Available to order

£260.96
  • Capacitive sensor
  • Operating voltage: 20-250 VAC
  • Rated switching distance: 15 mm
  • Flush mounting
  • Threaded barrel: M30 x 1.5
  • Material: Plastic (PA12-GF30)
  • Fine adjustment via potentiometer
  • AC 2-wire
  • Normally closed (NC) contact
  • Cable length: 2 meters

Read more

  • Cable connection


Product

Manufacturer Material ID -
BC10-S30-RZ3X
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Construction type housing -
Cylinder, screw-thread
Diameter sensor -
30 Millimetre
Housing material -
Plastic
Interface type -
Other
Length of sensor -
62.5 Millimetre
Mechanical mounting condition for sensor -
Concise
Rated control supply voltage at AC 50 Hz -
20 Volt
Rated control supply voltage at AC 60 Hz -
20 Volt
Supply voltage -
20 Volt
Switching distance -
15 Millimetre
Switching frequency -
20 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Cable
Type of interface for safety communication -
None
Type of switch function -
Breaker contact
Voltage type -
AC
Turck Banner

Availability Available to order

£260.96
