Magnetic Field Sensor, For Pneumatic Cylinders

Manufacturer's No: BIM-UNT-0.3-UNT-2AP6X3-H1141     Manufacturer: Turck Banner
Magnetic Field Sensor, For Pneumatic Cylinders

Availability On Request

£137.84
  • Magnetic Field Sensor for Pneumatic Cylinders
  • Operating Voltage: 10-30 VDC
  • Designed for T-groove cylinders without mounting accessories
  • Optional accessories available for mounting on other cylindrical housings
  • Allows one-hand mounting with tool for fine adjustment and stopper for direct mounting
  • Stable mounting for optimal performance
  • Ideal for monitoring two switching points on a cylinder
  • Magneto-resistive sensor with 2x NO contacts
  • PNP output, DC 4-wire
  • No Y-splitter required

Read more

  • Voltage Range: 10-30 VDC


Product

Manufacturer Material ID -
BIM-UNT-0.3-UNT-2AP6X3-H1141
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CH
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Cross-/short circuit identification possible -
Degree of protection (IP rating) -
IP67
Height of sensor -
22 Millimetre
Housing material -
Plastic
Length of sensor -
30 Millimetre
Rated supply voltage at DC -
10 Volt
Type of actuation -
Magnet
Type of electric connection -
Plug-in connection
Type of switching output -
PNP
Voltage type -
DC
Width sensor -
5 Millimetre
Turck Banner

Availability On Request

£137.84
