MINI-ARRAY: Emitter Sensor 448 (17.6 in), Beam Spacing: 19 (0.75 in), Total Beams = 24, System Range (w/ matching receiver) = 0.9-

Manufacturer's No: BMEL1816A     Manufacturer: Turck Banner
MINI-ARRAY: Emitter Sensor 448 (17.6 in), Beam Spacing: 19 (0.75 in), Total Beams = 24, System Range (w/ matching receiver) = 0.9-17 m, System Requires 2 Quick-Disconnect Cables

Availability Available to order

£586.51
  • Measuring Light Screen
  • Emitter
  • Operating Voltage: 11.4 - 14 VDC
  • Max. Sensing Range: 17 m
  • Max. Range: 17000 mm
  • Minimum Target Size: 19 mm
  • Scan Field: 448 mm
  • Operating Voltage (from controller): 11.8 - 12.2 VDC
  • Protection Class: IP65
  • Adjustment via software


Product

Manufacturer Material ID -
BMEL1816A
Net Weight -
1.11kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Height of sensor -
505 Millimetre
Length of sensor -
38.1 Millimetre
Resolution of the light curtain -
19 Millimetre
Safety field height -
438 Millimetre
Scope of delivery of the one-way system -
Transmitter
Type of electric connection -
Connector 7/8 inch
Wavelength of the sensor -
880 Nanometre
Width sensor -
38.1 Millimetre
Turck Banner

Availability Available to order

£586.51
