MINI-ARRAY: Emitter Sensor 143 (5.6 in), Beam Spacing: 19 (0.75 in), Total Beams = 8, System Range (w/ matching receiver) = 0.6 to

Manufacturer's No: BMEL616A     Manufacturer: Turck Banner
MINI-ARRAY: Emitter Sensor 143 (5.6 in), Beam Spacing: 19 (0.75 in), Total Beams = 8, System Range (w/ matching receiver) = 0.6 to 6.1 m, System Requires 2 Quick-Disconnect Cables

Availability On Request

£405.59
  • Measuring Light Screen
  • Emitter
  • Max. sensing range: 17 m
  • Max. range: 17000 mm
  • Minimum target size: 19 mm
  • Scan field: 143 mm
  • Operating voltage: 11.4…14 VDC
  • Operating voltage (from controller): 11.8…12.2 VDC
  • Protection class: IP65
  • Adjustment via software


Product

Manufacturer Material ID -
BMEL616A
Net Weight -
0.69kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Height of sensor -
201 Millimetre
Length of sensor -
38.1 Millimetre
Resolution of the light curtain -
19 Millimetre
Safety field height -
133 Millimetre
Scope of delivery of the one-way system -
Transmitter
Type of electric connection -
Connector 7/8 inch
Wavelength of the sensor -
880 Nanometre
Width sensor -
38.1 Millimetre
Turck Banner

Availability On Request

£405.59
