4012050 {T}

Inductive Sensor, Operating voltage Nom. 8.2 VDC, Rated switching distance

Manufacturer's No: BI2-EG12SK-Y1X     Manufacturer: Turck Banner
Inductive Sensor, Operating voltage Nom. 8.2 VDC, Rated switching distance

Availability Available to order

£90.99
  • Inductive Sensor
  • Rated switching distance: 2 mm
  • Flush mounting style
  • Threaded barrel: M12 x 1
  • Material: Stainless steel 1.4301
  • DC 2-wire, nominal voltage: 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • Terminal chamber included
  • ATEX category II 1 G, Ex zone 0
  • ATEX category II 1 D, Ex zone 20

Read more

  • Safety Integrity Level 2 (SIL2) in Low Demand Mode per IEC 61508
  • Performance Level c (PL c) according to ISO 13849-1 with HFT0
  • Safety Integrity Level 3 (SIL3) in All Demand Mode per IEC 61508
  • Performance Level e (PL e) according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
BI2-EG12SK-Y1X
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cylinder, screw-thread
Diameter sensor -
12 Millimetre
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 1G
Housing material -
Metal
Length of sensor -
65 Millimetre
Mechanical mounting condition for sensor -
Concise
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
2 Millimetre
Switching frequency -
5000 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Clamp
Type of switching output -
NAMUR
Voltage type -
DC
Turck Banner

Availability Available to order

£90.99
