D12 Series: High Power Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Complementary PNP, 150 (6 in) M8 P

Manufacturer's No: D12SP6FPHQ     Manufacturer: Turck Banner
D12 Series: High Power Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Complementary PNP, 150 (6 in) M8 Pigtail QD

Availability Available to order

POA
  • Type: Photoelectric Sensor for Plastic Fibers
  • Operating Voltage: 10-30 VDC
  • Cable Length: 0.15 m
  • Base Unit for plastic fibers
  • Connector: 8 mm
  • Output: PNP transistor switching
  • Sensitivity: Adjustable via potentiometer
  • Excess Gain: Very high
  • Indicator: 7-segment LED chain
  • Alarm Function included


Product

Manufacturer Material ID -
D12SP6FPHQ
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
CN
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
Other
Height amplifier -
30 Millimetre
Housing material -
Plastic
Length amplifier -
64 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
25 Milliampere
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Width amplifier -
12 Millimetre
