DX80 Performance 2.4 GHz Node 65 mW IP65, Integrated Battery External Antenna, Input: 2 Discrete, 4 Thermocouple, Output: 1 Discre

Manufacturer's No: DX80N2X1S-P3E     Manufacturer: Turck Banner
DX80 Performance 2.4 GHz Node 65 mW IP65, Integrated Battery External Antenna, Input: 2 Discrete, 4 Thermocouple, Output: 1 Discrete NMOS

Availability On Request

POA
  • Radio Transmission System with Star Topology
  • Node (FlexPower) with operating voltage of 3.6 to 5.5 VDC
  • Max. range of 3200000 mm
  • External antenna with RG58 RP-SMA connection
  • Integrated signal strength indicator
  • Configuration via DIP switch
  • Deterministic data transfer using Frequency Hopping Spread Spectrum (FHSS) and Time Division Multiplex Access (TDMA)
  • Transmission power: 63 mW (18 dBm conducted, ? 20 dBm EIRP)
  • Internal battery for power
  • Inputs: 2 x NPN, 4 x thermocouple

Read more

  • Outputs: 1 x NMOS


Product

Manufacturer Material ID -
DX80N2X1S-P3E
Net Weight -
0.74kg

Additional Product Information

Commodity Code -
85176200
Country of Origin -
US
UNSPSC -
32151701
Turck Banner

Availability On Request

POA
