50130445

The Signaling column element from . Signaling: Optical; Supply voltage: 24 V, AC/DC; Current consumption, max.: 27 mA; Design: Cyl

Manufacturer's No: E4-V1-DS-B     Manufacturer: Leuze
The Signaling column element from . Signaling: Optical; Supply voltage: 24 V, AC/DC; Current consumption, max.: 27 mA; Design: Cylindrical; Diameter: 40 mm; Fastening: Bayonet system; Illuminant: LE

Availability Back Order

£35.00
  • Signaling: Optical
  • Supply Voltage: 24 V AC/DC
  • Current Consumption: 27 mA (max)
  • Design: Cylindrical
  • Diameter: 40 mm
  • Fastening: Bayonet system
  • Illuminant: LED/24V
  • Signal Image: Continuous light
  • Lens Color: Blue
  • Angle of Radiation: 360°

Read more

  • Ambient Temperature: -30 to 60 °C
  • Degree of Protection: IP 66

Accessories



Product

Manufacturer Material ID -
E4-V1-DS-B
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85318070
Country of Origin -
AT
UNSPSC -
32151500

Technical Specification

Lamp type -
UN
Operating voltage at DC -
- Volt
Degree of protection (NEMA) -
UN
Colour housing -
Blue
Degree of protection (IP) -
IP66
Thumbnail of product picture -
Colour -
Blue
Degree of protection (IP rating) -
IP66
Function -
Continuous light
Housing colour -
Black
Light source type -
LED
Operating voltage at AC 50 Hz -
24 Volt
Operating voltage at AC 60 Hz -
24 Volt
Outer diameter -
40 Millimetre
Voltage type -
AC/DC
Leuze

Availability Back Order

£35.00
