3015156

EA5R600XKQ EZ-ARRAY 5 Optical Spacing x 600 RECVR with IO-Link Integral 8-pin M12

Manufacturer's No: EA5R600XKQ     Manufacturer: Turck Banner
EA5R600XKQ EZ-ARRAY 5 Optical Spacing x 600 RECVR with IO-Link Integral 8-pin M12

Availability On Request

£1,332.00
  • Measuring Light Screen
  • Receiver with Male M12 × 1, 8-pin connector
  • Max. range: 4 m with a resolution of 5 mm
  • Operating voltage: 18-30 VDC
  • Protection class: IP65
  • IO-Link communication and PNP switching output
  • Includes 2 × EZA-MBK-11 brackets
  • Extension cable required between emitter and splitter (type DEE2R-8xxD)
  • Includes IO-Link splitter CSB-M1240M1280
  • Analog output: 0-10 V via splitter CSB-M1250M1280 (sold separately)

Read more

  • 2 × PNP switching output and 2 × analog outputs 0-10 V


Product

Manufacturer Material ID -
EA5R600XKQ
Net Weight -
2.26kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
MX
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Fade-out possible -
Height of sensor -
678 Millimetre
Length of sensor -
45.2 Millimetre
Reaction time -
9.3 Millisecond
Resolution of the light curtain -
5 Millimetre
Safety field height -
600 Millimetre
Type of electric connection -
Connector M12
Type of switching output of the OSSD -
PNP/NPN
Width sensor -
36 Millimetre
Turck Banner

Availability On Request

£1,332.00
