1SKT131201C0001

EPP-W312 Protecta plus DB, 450 mm x 125 mm x 870 mm, Isolated (Class II), IP43

Manufacturer's No: EPP-W312     Manufacturer: ABB
EPP-W312 Protecta plus DB, 450 mm x 125 mm x 870 mm, Isolated (Class II), IP43

Availability Back Order

£441.91
EPP-W312 DB 12 Way 250A


Product

Manufacturer Material ID -
EPP-W312
Net Weight -
18.00kg

Additional Product Information

Commodity Code -
85.38.12
Country of Origin -
EG
UNSPSC -
31261502

Technical Specification

Circuit integrity -
None
Colour -
Grey
Cover model -
Closed
Degree of protection (IP rating) -
IP43
Depth -
870 Millimetre
Extension possible -
Height -
450 Millimetre
Housing material -
Steel
Impact resistance (IK rating) -
IK07
Internal depth -
129 Millimetre
Mounting method -
Surface mounted
Nominal current (In) -
250 Ampere
Number of modules -
36
Number of openings for flange plates -
2
Plate thickness cabinet -
1 Millimetre
Plate thickness door/cover -
1 Millimetre
Protection class -
II
RAL number -
7035
Recess depth -
130 Millimetre
Surface protection -
Powder coated
Type of covering -
Door
Type of door -
Compartment door
Width -
125 Millimetre
With lock -
ABB

Availability Back Order

£441.91
