7540045

Isolating transducer, 1-channel

Manufacturer's No: IM43-14-CDRI     Manufacturer: Turck Banner
Isolating transducer, 1-channel

Availability On Request

£615.98
  • Isolating transducer, 1-channel
  • Operating voltage: 20-250 VAC / 20-250 VDC
  • Input circuit: 0/4-20 mA; 0/2-10 V
  • Output circuit: 0/4-20 mA
  • 3 independent limit value relays
  • Monitors over and underrange of analog values and window limits
  • Connection of passive 2-wire and active 3-wire transmitters
  • Parameterized via PC (FDT / DTM), front-panel switch and HART®
  • Many diagnostic functions
  • Ring buffer for up to 8000 measured values

Read more

  • Display
  • Complete galvanic isolation
  • Input reverse-polarity protected
  • TR CU


Product

Manufacturer Material ID -
IM43-14-CDRI
Net Weight -
0.25kg

Additional Product Information

Commodity Code -
85437090990
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Construction type of device -
Built-in device
Degree of protection (IP rating) -
IP20
Depth -
104 Millimetre
Height -
110 Millimetre
Mounting method -
Snap mounting support rail
Number of input ranges 0 mA ... 20 mA -
1
Number of input ranges 0 V ... 10 V -
1
Number of input ranges 2 V ... 10 V -
1
Number of input ranges 4 mA ... 20 mA -
1
Operating temperature -
-25 Degrees celsius
Power consumption -
3 Watt
Rated operation frequency -
40 Hertz
Rated supply voltage at AC -
20 Volt
Rated supply voltage at DC -
20 Volt
Switching frequency -
10 Hertz
Temperature drift -
0.0025 Temperature coefficient
Type of electric connection -
Screw connection
Width -
27 Millimetre
Turck Banner

Availability On Request

£615.98
