6611420

PROFIBUS-PA, IP67 junction box, 4-channel

Manufacturer's No: JBBS-48-T415/3G     Manufacturer: Turck Banner
PROFIBUS-PA, IP67 junction box, 4-channel

Availability On Request

£274.35
  • PROFIBUS-PA 4-channel IP67 junction box
  • Operating voltage: 9-32 VDC
  • Wall-mountable with PVC cable glands M20 x 1.5
  • Integrated terminating resistor (activatable)
  • Cable shielding: Capacitive or direct connection to housing potential selectable
  • Isolated support terminal for optional protective conductor
  • Powder-coated die-cast aluminium housing
  • Pressure compensation element prevents condensation
  • Connection of housing potential via M5 x 1 bolt
  • Entity and FISCO compliant (IEC 60079-11)


Product

Manufacturer Material ID -
JBBS-48-T415/3G
Net Weight -
0.65kg

Additional Product Information

Commodity Code -
85369095000
Country of Origin -
DE
UNSPSC -
32151705
Turck Banner

Availability On Request

£274.35
