6611409 {T}

IP67 Junction Box, 4-Channel, PROFIBUS-PA, Operating voltage 12

Manufacturer's No: JBBS-48SC-E413/EX     Manufacturer: Turck Banner
IP67 Junction Box, 4-Channel, PROFIBUS-PA, Operating voltage 12

Availability Available to order

£747.25
  • PROFIBUS-PA junction box with IP67 rating
  • 4-channel design with an operating voltage of 12-32 VDC
  • Wall-mountable junction box with stainless steel M12 flange connections
  • Short-circuit protection per drop line/spur
  • Integrated terminating resistor (activatable)
  • Cable shielding options: Capacitive or direct connection to housing potential
  • Isolated support terminal for optional protective conductor in cable
  • Powder-coated die-cast aluminium housing
  • Pressure compensation element prevents condensation
  • Connection of housing potential via M5 x 1 bolt

Read more

  • Entity and FISCO compliant according to IEC 60079-11


Product

Manufacturer Material ID -
JBBS-48SC-E413/EX
Net Weight -
0.71kg

Additional Product Information

Commodity Code -
85369095000
Country of Origin -
DE
UNSPSC -
32151705
Turck Banner

Availability Available to order

£747.25
