PROFIBUS-PA, IP67 junction box, 4-channel

Manufacturer's No: JBBS-48SC-T415B/EX     Manufacturer: Turck Banner
PROFIBUS-PA, IP67 junction box, 4-channel

Availability On Request

£456.43
  • PROFIBUS-PA 4-channel IP67 junction box
  • Operating voltage: 12-32 VDC
  • Wall-mountable with PVC cable glands M20 x 1.5
  • Short-circuit protection per drop line/spur
  • Integrated activatable terminating resistor
  • Cable shielding: Capacitive or direct connection to housing potential
  • Isolated support terminal for optional protective conductor
  • Powder-coated die-cast aluminium housing
  • Pressure compensation element prevents condensation
  • Connection of housing potential via M5 x 1 bolt

Read more

  • Entity and FISCO compliant with IEC 60079-11


Product

Manufacturer Material ID -
JBBS-48SC-T415B/EX
Net Weight -
0.66kg

Additional Product Information

Commodity Code -
85369095000
Country of Origin -
DE
UNSPSC -
32151705
Turck Banner

Availability On Request

£456.43
