6611436 {T}

IP67 Junction Box, 4-Channel, FOUNDATION Fieldbus, Operating voltage 12

Manufacturer's No: JBBS-49SC-M413/3G     Manufacturer: Turck Banner
IP67 Junction Box, 4-Channel, FOUNDATION Fieldbus, Operating voltage 12

Availability Available to order

£680.72
  • FOUNDATION fieldbus, IP67 junction box
  • 4-channel with operating voltage of 12-32 VDC
  • Wall-mountable junction box with stainless steel 7/8" flange connections
  • Short-circuit protection per drop line/spur
  • Integrated terminating resistor (activatable)
  • Cable shielding: Capacitive or direct connection to housing potential selectable via switch
  • Isolated support terminal for optional protective conductor in cable
  • Powder-coated die-cast aluminium housing
  • Pressure compensation element protects against condensation
  • Connection of housing potential via M5 x 1 bolt

Read more

  • Entity and FISCO compliant according to IEC 60079-11


Product

Manufacturer Material ID -
JBBS-49SC-M413/3G
Net Weight -
0.78kg

Additional Product Information

Commodity Code -
85369095000
Country of Origin -
DE
UNSPSC -
32151705
Turck Banner

Availability Available to order

£680.72
