3057571

LG5 Series: Laser Displacement Sensor; Range: 4560 mm; Input: 1230 V dc; Output: Discrete: NPN Analog: 010 V dc; 2 m 6.5 ft Cable;

Manufacturer's No: LG5A65NU
LG5 Series: Laser Displacement Sensor; Range: 4560 mm; Input: 1230 V dc; Output: Discrete: NPN Analog: 010 V dc; 2 m 6.5 ft Cable;

Availability Back Order

POA
  • Model: LG5 Series Laser Displacement Sensor
  • Range: 4560 mm
  • Input: 1230 V dc
  • Output: Discrete NPN, Analog 0-10 V dc
  • Cable Length: 2 meters (6.5 feet)


Product

Manufacturer Material ID -
LG5A65NU
Net Weight -

Additional Product Information

UNSPSC -
39122216

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
55.3 Millimetre
Housing material -
Other
Laser protection class -
Class 2
Length of sensor -
82.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Setting procedure -
Manual adjustment
Supply voltage -
12 Volt
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
NPN
Width sensor -
20.2 Millimetre


Availability Back Order

POA
