EZ-SCREEN TYPE 2, LATCH Output, E/R Pair, 30 Resolution, 600 Defined Area, 15 m Range, Yellow Housing, 8-pin M12 Integral QD, Moun

Manufacturer's No: LS2LP30-600Q88     Manufacturer: Turck Banner
EZ-SCREEN TYPE 2, LATCH Output, E/R Pair, 30 Resolution, 600 Defined Area, 15 m Range, Yellow Housing, 8-pin M12 Integral QD, Mounting Hardware Included

Availability On Request

£1,655.93
  • Light screen for machine safety applications
  • Emitter/Receiver pair
  • Max. range: 15,000 mm
  • Scan field: 600 mm
  • Resolution: 30 mm
  • Range: 15 m
  • Operating voltage: 20-28 VDC
  • M12 x 1 male connector, 8-pin
  • Protection class: IP65
  • Internal testing in 500-ms cycle

Read more

  • Operating voltage: 24 VDC ± 15%
  • Switching output with restart interlock (LATCH)
  • Muting is not supported
  • Type 2 according to IEC 61496-1, -2
  • Category 2 PL d according to EN ISO 13849-1
  • SIL 2 according to IEC 61508


Product

Manufacturer Material ID -
LS2LP30-600Q88
Net Weight -
0.24kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CN
UNSPSC -
39122216

Technical Specification

Ambient temperature -
0 Degrees celsius
Height of sensor -
665 Millimetre
Length of sensor -
31.8 Millimetre
Max. output current at protected output -
500 Milliampere
Number of protected semiconductor outputs -
2
Reaction time -
16 Millisecond
Resolution of the light curtain -
30 Millimetre
Safety field height -
600 Millimetre
Suitable for safety functions -
Type of electric connection -
Connector M12
Type of switching output of the OSSD -
PNP
Wavelength of the sensor -
950 Nanometre
Width sensor -
25.2 Millimetre
With restart blockage -
Turck Banner
