1SBV013841R1211

LS33M41B11 Limit Switch

Manufacturer's No: LS33M41B11     Manufacturer: ABB
LS33M41B11 Limit Switch

Availability Available to order

£37.53
  • Product: LS33M41B11 Limit Switch
  • Width: 30 mm
  • Material: Zinc alloy (Zamak)
  • Mounting: 2 holes at the top
  • Cable Entry: 1 ISO M20x1.5 on the bottom
  • Actuator: Plastic roller lever (Ø18 mm)
  • Contacts: 1 N.O + 1 N.C snap action (Zb type)


Product

Manufacturer Material ID -
LS33M41B11
Net Weight -
0.24kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
IT
Minimum Order Quantity -
10
UNSPSC -
39121529

Technical Specification

Material housing -
UN
Type of switching contact -
UN
Number of cams -
-
Cam distance -
- Millimetre
Plunger orientation -
UN
Degree of protection (IP) -
UN
Type of interface -
UN
Degree of protection (NEMA) -
UN
Alignment of the control element -
Other
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Powder coated
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66
Diameter sensor -
0 Millimetre
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Height of sensor -
108 Millimetre
Housing material -
Metal
Interface type -
None
Length of sensor -
44 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of safety auxiliary contacts -
0
Rated operation current Ie at AC-15, 125 V -
5.5 Ampere
Rated operation current Ie at AC-15, 230 V -
3.1 Ampere
Rated operation current Ie at AC-15, 24 V -
10 Ampere
Rated operation current Ie at DC-13, 125 V -
0.6 Ampere
Rated operation current Ie at DC-13, 230 V -
0.4 Ampere
Rated operation current Ie at DC-13, 24 V -
6 Ampere
Switching function -
Quick-break switch
Type of control element -
Plunger
Type of electric connection -
Cable entry metrical
Type of interface for safety communication -
None
Width sensor -
30 Millimetre
ABB

Availability Available to order

£37.53
