3801131

Laser Diffuse Time-of-Flight Sensor, Range: 50-12000, Input: 12-30 V dc, Output 1: NPN/PNP Configurable, IO-Link, Output 2: NPN/PN

Manufacturer's No: LTF12KC2LDQP     Manufacturer: Turck Banner
Laser Diffuse Time-of-Flight Sensor, Range: 50-12000, Input: 12-30 V dc, Output 1: NPN/PNP Configurable, IO-Link, Output 2: NPN/PNP Configurable, Class 2 Laser, Pigtail QD

Availability On Request

£706.83
  • Photoelectric Sensor, Diffuse-Mode Laser Sensor
  • Operating voltage: 12-30 VDC
  • Max. range: 12000 mm
  • Cable length: 0.15 m, PVC material
  • 2-line, 8-segment display
  • Laser class 2, red, 660 nm
  • Range: 0.05-12 m
  • Resolution: 0.3-3 mm
  • Output 1: PNP switching output with IO-Link communication
  • Output 2: PNP switching output, alarm output, or pulse frequency modulation (PFM)

Read more

  • Transmission of process value and parametrization via IO-Link


Product

Manufacturer Material ID -
LTF12KC2LDQP
Net Weight -
0.40kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
43211902

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
56 Millimetre
Housing material -
Other
Laser protection class -
Class 2
Length of sensor -
77 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Standard for interfaces -
Other
Supply voltage -
12 Volt
Switching frequency -
250 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Width sensor -
26 Millimetre
