MAR1216NX485Q 16CH 2-STICK MA RECEIVER

Manufacturer's No: MAR1216NX485Q     Manufacturer: Turck Banner
MAR1216NX485Q 16CH 2-STICK MA RECEIVER

Availability Available to order

£580.30
  • Measuring Light Screen
  • Receiver with 150 mm cable and male connector (M12 × 1, 8-pin)
  • Max. range: 16.5 m
  • Scan field (Y): 295 mm
  • Resolution: 19 mm
  • Operating voltage: 16-30 VDC
  • 2 reversible switching outputs (NPN/PNP)
  • RS485 interface


Product

Manufacturer Material ID -
MAR1216NX485Q
Net Weight -
0.89kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Height of sensor -
384 Millimetre
Length of sensor -
38.1 Millimetre
Reaction time -
9.6 Millisecond
Resolution of the light curtain -
9.5 Millimetre
Safety field height -
295 Millimetre
Type of electric connection -
Connector M12
Type of switching output of the OSSD -
PNP/NPN
Width sensor -
38.1 Millimetre
Turck Banner

Availability Available to order

£580.30
