Inductive Sensor, Ring Sensor

Manufacturer's No: NI100R-S32XL-VP44X-H1141     Manufacturer: Turck Banner
Inductive Sensor, Ring Sensor

Availability On Request

POA
  • Inductive Sensor
  • Ring Sensor
  • Operating Voltage: 10-55 VDC
  • Rectangular shape, height: 32 mm
  • Material: Plastic (POM)
  • Integrated amplifier
  • Sensitivity adjustable via potentiometer
  • Output pulse length minimum: 100 ms
  • Short-circuit and reverse-polarity protection
  • Wide temperature range

Read more

  • High resolution, switching accuracy, and repeatability
  • DC 4-wire, 10-55 VDC
  • Changeover contact, PNP output
  • Connector: M12 x 1 male


Product

Manufacturer Material ID -
NI100R-S32XL-VP44X-H1141
Net Weight -
0.12kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Construction type housing -
Special construction
Height of sensor -
32 Millimetre
Housing material -
Plastic
Length of sensor -
180 Millimetre
Supply voltage -
10 Volt
Switching frequency -
8 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switch function -
Change-over contact
Type of switching output -
PNP
Voltage type -
DC
Width sensor -
137.5 Millimetre
Turck Banner

Availability On Request

POA
