1515510

Inductive Sensor, With Extended Switching Distance

Manufacturer's No: NI100U-K90SR-VN4X2-H1141     Manufacturer: Turck Banner
Inductive Sensor, With Extended Switching Distance

Availability On Request

£440.13
  • Inductive Sensor
  • Extended switching distance: 100 mm
  • Operating voltage: 10-65 VDC
  • Non-flush, rectangular design with a height of 60 mm
  • Material: Plastic (PBT-GF30-V0)
  • Factor 1 for all metals
  • Protection class: IP68
  • Resistant to magnetic fields
  • Extended temperature range
  • Auto-compensation protects against pre-damping

Read more

  • One-sided fitting possible
  • DC 4-wire
  • Changeover contact
  • NPN output
  • Connector: M12 x 1 male


Product

Manufacturer Material ID -
NI100U-K90SR-VN4X2-H1141
Net Weight -
0.77kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Surface protection -
UN
Working temperature -
- Degrees celsius
Max. conductor cross section -
- Square millimetre
Degree of protection (NEMA) -
UN
Mounting method -
Surface mounted (plaster)
Colour -
Grey
Width -
300 Millimetre
Depth -
80 Millimetre
Rated insulation voltage Ui -
0 Volt
Length -
300 Millimetre
Type of inlet -
Swivel
Circuit integrity -
None
Material -
Other
Number of inlets -
0
Impact strength -
IK08
Cover attachment -
Screwed
Degree of protection (IP) -
IP66
For Ex-zone gas -
None
For Ex-Zone dust -
None
Plate thickness cabinet -
125 Millimetre
Construction type housing -
Cuboid
Height of sensor -
60 Millimetre
Housing material -
Plastic
Length of sensor -
130 Millimetre
Mechanical mounting condition for sensor -
Not flat
Supply voltage -
10 Volt
Switching distance -
100 Millimetre
Switching frequency -
250 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switch function -
Change-over contact
Type of switching output -
NPN
Voltage type -
DC
Width sensor -
75 Millimetre
Turck Banner

Availability On Request

£440.13
