Inductive Sensor

Manufacturer's No: NI20-CK40-Y1X-H1141     Manufacturer: Turck Banner
Inductive Sensor

Availability On Request

POA
  • Inductive Sensor
  • Rated switching distance: 20 mm
  • Non-flush, Rectangular design with a height of 40 mm
  • Variable orientation of active face in 5 directions
  • Material: Plastic (PBT?GF30?V0)
  • DC 2-wire, nominal voltage: 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • M12 x 1 male connector
  • ATEX category II 2 G, Ex Zone 1
  • ATEX category II 1 D, Ex Zone 20

Read more

  • SIL 2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 at HFT0
  • SIL 3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
NI20-CK40-Y1X-H1141
Net Weight -
0.21kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
41111926

Technical Specification

Coating housing -
Other
Construction type housing -
Cuboid
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 2G
Height of sensor -
40 Millimetre
Housing material -
Plastic
Length of sensor -
65 Millimetre
Mechanical mounting condition for sensor -
Not flat
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
20 Millimetre
Switching frequency -
150 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
40 Millimetre
