1535544

Inductive Sensor, With Analog Output

Manufacturer's No: NI25-CP40-LIU     Manufacturer: Turck Banner
Inductive Sensor, With Analog Output

Availability On Request

£245.57
  • Inductive sensor with analog output
  • Operating voltage: 15-30 VDC
  • Measuring range: 5 mm to 25 mm
  • Non-flush, rectangular design with a height of 40 mm
  • Active face can be oriented in 9 directions
  • Made of plastic (PBT-GF30-VO)
  • Features high-luminance corner LEDs
  • Provides optimum visibility of operating voltage and switching state from any angle
  • 4-wire connection
  • Analog output: 0-10 V and 0-20 mA

Read more

  • Equipped with a terminal chamber


Product

Manufacturer Material ID -
NI25-CP40-LIU
Net Weight -
0.22kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
40 Millimetre
Housing material -
Plastic
Length of sensor -
114 Millimetre
Limiting frequency -
30 Hertz
Material active area of sensor -
Plastic
Measuring range length -
5 Millimetre
Mechanical mounting condition for sensor -
Not flat
Operating voltage -
15 Volt
Relative linearity deflection -
5 Percentage
Supply voltage -
15 Volt
Type of analogy output -
0 V ... 10 V
Type of electric connection -
Clamp
Width sensor -
40 Millimetre
Turck Banner

Availability On Request

£245.57
