4602850 {T}

Inductive Sensor, Operating voltage 10…30 VDC, Rated switching distance

Manufacturer's No: NI3-EG08-AN6X-V1131     Manufacturer: Turck Banner
Inductive Sensor, Operating voltage 10…30 VDC, Rated switching distance

Availability Available to order

£120.02
  • Inductive sensor
  • Operating voltage: 10-30 VDC
  • Rated switching distance: 3 mm
  • Non-flush
  • Threaded barrel: M8 x 1
  • Material: Stainless steel 1.4305 (AISI 303)
  • Output: DC 3-wire, NPN
  • Contact type: NO
  • Connector: M8 x 1 male


Product

Manufacturer Material ID -
NI3-EG08-AN6X-V1131
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CH
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cylinder, screw-thread
Diameter sensor -
8 Millimetre
Housing material -
Metal
Length of sensor -
49 Millimetre
Mechanical mounting condition for sensor -
Not flat
Supply voltage -
10 Volt
Switching distance -
3 Millimetre
Switching frequency -
3000 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switch function -
Normally open contact
Type of switching output -
NPN
Voltage type -
DC
Turck Banner

Availability Available to order

£120.02
