1050001

Inductive Sensor, For Rotary Actuators

Manufacturer's No: NI4-DS20-2Y1X2-H1140     Manufacturer: Turck Banner
Inductive Sensor, For Rotary Actuators

Availability On Request

£150.71
  • Inductive sensor for rotary actuators
  • Rated switching distance: 4 mm
  • Non-flush rectangular housing DS20 made of Plastic PBT?GF30?VO
  • Two switching outputs for monitoring rotary actuator position
  • Mounts on all standard actuators
  • DC 2-wire, nominal 8.2 VDC
  • 2 outputs according to DIN EN 60947-5-6 (NAMUR)
  • M12 x 1 male connector
  • ATEX category II 1 G, Ex zone 0
  • ATEX category II 1 D, Ex zone 20

Read more

  • SIL2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 with HFT0
  • SIL3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
NI4-DS20-2Y1X2-H1140
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 1G
Height of sensor -
20 Millimetre
Housing material -
Plastic
Length of sensor -
42 Millimetre
Mechanical mounting condition for sensor -
Not flat
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
4 Millimetre
Switching frequency -
50 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
45 Millimetre
Turck Banner

Availability On Request

£150.71
