PicoDot: Polarized Retro Laser, Range: depends on reflector, Input: 10-30 V dc, Outputs: Complementary PNP, 150 (6 in) M12 Pigtail

Manufacturer's No: PD45VP6LLPQ     Manufacturer: Turck Banner
PicoDot: Polarized Retro Laser, Range: depends on reflector, Input: 10-30 V dc, Outputs: Complementary PNP, 150 (6 in) M12 Pigtail QD

Availability On Request

£605.21
  • Photoelectric Sensor
  • Retroreflective Laser Sensor
  • Operating Voltage: 10-30 VDC
  • Max. Range: 10.6 m
  • Cable Length: 0.15 m
  • Laser sensors with high excess gain
  • BRT-36X40BM reflector included
  • M12 x 1 male connector
  • Sensitivity adjusted via potentiometer
  • Light and dark operation


Product

Manufacturer Material ID -
PD45VP6LLPQ
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-10 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP54
Height of sensor -
40.6 Millimetre
Housing material -
Plastic
Laser protection class -
Class 2
Length of sensor -
45.6 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
10600 Millimetre
Rated switching distance -
10600 Millimetre
Reaction time -
0.2 Millisecond
Setting procedure -
Other
Type of electric connection -
Connector M12
Type of light -
Polarized red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
650 Nanometre
Width sensor -
12.7 Millimetre
