Pressure sensor, 2 PNP/NPN Transistor Switching Outputs

Manufacturer's No: PS250R-304-2UPN8X-H1141     Manufacturer: Turck Banner
Pressure sensor, 2 PNP/NPN Transistor Switching Outputs

Availability On Request

£514.77
  • Pressure sensor with 2 PNP/NPN transistor switching outputs
  • Operating voltage: 18 to 30 VDC
  • Rigid process connection with non-rotatable body
  • Reading of adjusted values without tool
  • Secure programming with recessed pushbutton and keylock
  • Permanent indication of pressure in bar, psi, kPa, MPa, and misc
  • Peak pressure memory feature
  • Pressure range: 0 to 250 bar rel.

Follow-up article



Product

Manufacturer Material ID -
PS250R-304-2UPN8X-H1141
Net Weight -
0.25kg

Additional Product Information

Commodity Code -
90262020000
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Bursting pressure -
500 Pressure
Degree of protection (IP rating) -
IP67
End setting -
250000 Hecto Pascal
End value measuring range pressure -
25000000 Pascal
Engaging pressure -
0 Pressure
Initial setting -
0 Hecto Pascal
Initial value measuring range pressure -
0 Pascal
Max. test pressure -
500 Pressure
Medium temperature -
-40 Degrees celsius
Rated voltage Ue at DC -
18 Volt
Switch off pressure -
250 Pressure
Type of electric connection -
Other
