Pick-to-Light, Placement Sensor, Light Grid

Manufacturer's No: PVA225N6RQ     Manufacturer: Turck Banner
Pick-to-Light, Placement Sensor, Light Grid

Availability Available to order

POA
  • Pick-to-Light system with Placement Sensor and Light Grid
  • Operating voltage: 12-30 VDC
  • Max. range: 2000 mm
  • Cable length: 2 m
  • Scan field Y: 225 mm
  • Total height: 266.4 mm
  • 10-beam system with beam spacing of 25 mm
  • Receiver with max. range of 2 m
  • Light/Dark operation with selectable frequency for crosstalk protection
  • NPN switching output of the receiver

Read more

  • Input of operation request light: +24 VDC
  • Protection class: IP62


Product

Manufacturer Material ID -
PVA225N6RQ
Net Weight -
0.31kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216
