3044861

Q10 Series: Diffuse, Range: 0.5 m, Input: 10-30 V dc, Output: Light Operate - PNP, 2 m (6.5 ft) Cable

Manufacturer's No: Q10AP6D     Manufacturer: Turck Banner
Q10 Series: Diffuse, Range: 0.5 m, Input: 10-30 V dc, Output: Light Operate - PNP, 2 m (6.5 ft) Cable

Availability On Request

£137.92
  • Photoelectric sensor in diffuse mode
  • Miniature sensor with a max range of 500 mm
  • Operating voltage: 10-30 VDC
  • Cable length: 2 m
  • Protection class: IP67
  • Glass lens for light operation
  • PNP/NPN switching output


Product

Manufacturer Material ID -
Q10AP6D
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CN
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
10 Millimetre
Housing material -
Plastic
Length of sensor -
35 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Glass
Max. switching distance -
500 Millimetre
Reaction time -
3 Millisecond
Sensing mode -
Light switching
Type of electric connection -
Cable
Type of light -
Infrared light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP
Wavelength of the sensor -
880 Nanometre
Width sensor -
20 Millimetre
Turck Banner

Availability On Request

£137.92
