3044752

Q10 Series: Receiver, Range: 1.8 m, Input: 10-30 V dc, Output: Light Operate - PNP, 2 m (6.5 ft) Cable

Manufacturer's No: Q10AP6R     Manufacturer: Turck Banner
Q10 Series: Receiver, Range: 1.8 m, Input: 10-30 V dc, Output: Light Operate - PNP, 2 m (6.5 ft) Cable

Availability On Request

£82.57
  • Type: Photoelectric Sensor (Opposed Mode - Receiver)
  • Miniature sensor with a glass lens
  • Operating Voltage: 10-30 VDC
  • Max. Range: 1800 mm
  • Cable Length: 2 m
  • Protection Class: IP67
  • Output: PNP/NPN switching output
  • Light operation


Product

Manufacturer Material ID -
Q10AP6R
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CN
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
10 Millimetre
Housing material -
Plastic
Length of sensor -
21.6 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Glass
Max. switching distance -
1800 Millimetre
Rated switching distance -
1800 Millimetre
Reaction time -
8 Millisecond
Sensing mode -
Light switching
Type of electric connection -
Cable
Type of light -
Infrared light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP
Wavelength of the sensor -
880 Nanometre
Width sensor -
20 Millimetre
Turck Banner

Availability On Request

£82.57
