74138 {B}

WORLD-BEAM Q12 Series: Emitter, Range: 2 m, Input 10-30 V dc, Output: No outputs, 150 (6 in) M12 Pigtail QD

Manufacturer's No: Q126EQ5     Manufacturer: Turck Banner
WORLD-BEAM Q12 Series: Emitter, Range: 2 m, Input 10-30 V dc, Output: No outputs, 150 (6 in) M12 Pigtail QD

Availability Available to order

£86.42
  • Type: Photoelectric Sensor, Opposed Mode (Emitter)
  • Miniature sensor with a compact design
  • Operating Voltage: 10-30 VDC
  • Maximum Range: 2000 mm
  • Cable Length: 0.15 m
  • Cable Type: PVC, 4-pin with M12 × 1 male end
  • Protection Class: IP67
  • LED indicator visible from all angles


Product

Manufacturer Material ID -
Q126EQ5
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
26.6 Millimetre
Housing material -
Plastic
Length of sensor -
12.4 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
2000 Millimetre
Rated switching distance -
2000 Millimetre
Reaction time -
1.3 Millisecond
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Wavelength of the sensor -
640 Nanometre
Width sensor -
8 Millimetre
Turck Banner

Availability Available to order

£86.42
