3077111

WORLD-BEAM Q12 Series: Polarized Retro, Range: 1 m, Input: 10-30 V dc, Output: LO, 1 NPN, 150 (6 in) 3-pin M8 Pigtail QD

Manufacturer's No: Q12AN6LPQ3     Manufacturer: Turck Banner
WORLD-BEAM Q12 Series: Polarized Retro, Range: 1 m, Input: 10-30 V dc, Output: LO, 1 NPN, 150 (6 in) 3-pin M8 Pigtail QD

Availability On Request

£139.73
  • Photoelectric sensor with polarizing filter
  • Retroreflective sensor
  • Miniature sensor
  • Operating voltage: 10-30 VDC
  • Max. range: 1000 mm
  • Cable length: 0.15 m, PVC material
  • M8 × 1 male end, 3-pin connector
  • Protection class: IP67
  • LED all-round visible
  • Indication of insufficient excess gain

Read more

  • Glass lens
  • NPN switching output
  • Light operation


Product

Manufacturer Material ID -
Q12AN6LPQ3
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
26.6 Millimetre
Housing material -
Plastic
Length of sensor -
12.4 Millimetre
Material of optical surface -
Glass
Max. switching distance -
1000 Millimetre
Rated switching distance -
1000 Millimetre
Reaction time -
0.7 Millisecond
Switching frequency -
700 Hertz
Type of electric connection -
Connector M8
Type of light -
Polarized red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
NPN
Wavelength of the sensor -
640 Nanometre
Width sensor -
8 Millimetre
Turck Banner

Availability On Request

£139.73
